Detailed Product Description
| Condition: | New | Application: | Plastic Processing Mixer |
| Automatic Grade: | Semi-Automatic | Production Capacity: | 200kg/batch |
| Voltage: | 380V/50Hz/3Phase As Usual | Power(W): | 40/55 Kw |
| Dimension(L*W*H): | 2800*1080*1680 | Weight: | 180kgs |
| Warranty: | 1 Year | After-sales Service Provided: | Engineers Available To Service Machinery Overseas |
| Keywords: | PE PP Plastic Compound Raw Material Mixer 200 L | Rotate Speed: | 475/950rpm |
| Material: | Stainless Steel | Material Processed:: | PVC, PE, PP |
| Capacity: | 150kg | Quality Control: | Easy Operate |
| Usage: | Mixing Drying Colouring | Color: | Optional |
| Mixing Time: | 8-12min |
Welcome to Dongyue Electrical
PVC PE PP plastic compound raw material mixer 200 L
Product Description
PVC PE PP plastic compound raw material mixer 200 L
| Type | Volume (L) | Effective
Volume (L) |
Mixing time
(min/batch) |
Rotate speed
(r/min) |
Motor
(Kw) |
Capacity
(kg/hour) |
| SHR-5 | 5 | 3 | 6-8 | 1500 | 1.1 | 10 |
| SHR-10 | 10 | 7 | 6-8 | 1500 | 3 | 20 |
| SHR-25 | 25 | 20 | 6-8 | 1500 | 5.5 | 50 |
| SHR-50 | 50 | 35 | 6-10 | 750/1500 | 7/11 | 100 |
| SHR-100 | 100 | 75 | 6-10 | 650/1300 | 14/22 | 200 |
| SHR-200 | 200 | 150 | 6-10 | 475/950 | 30/42 | 400 |
| SHR-300 | 300 | 225 | 6-10 | 430/860 | 40/55 | 500 |
| SHR-500 | 500 | 375 | 8-12 | 330/660 | 55/75 | 800 |
| SHR-800 | 800 | 520 | 8-12 | 395/790 | 83/110 | 1400 |
| SHR-1000 | 1000 | 650 | 8-14 | 330/660 | 90/132 | 1600 |
| SHR-1300 | 1300 | 850 | 8-14 | 330/660 | 132/200 | 2100 |
Plastic material high speed hot mixer , SHR plastic horizontal mixter , plastic mixer , plastic high speed mixter
1.composed of high speed hot mixer, cold mixer…
2.mixing fast and even
3.easily cleaning, compact.
Mainly composed of high speed hot mixer, cold mixer, and electric control components etc. It is widely used in drying mixing blending and cooling the powder, liquid, granulate of plastics, rubber, dyestuffs, foodstuffs, chemical, Caco3 etc.
Plastic material high speed hot mixer ,SHR plastic horizontal mixter , plastic mixer , plastic high speed mixter
1.It is used in mixing, drying, coloring and other processing. It is the most ideal equipment for producing shaped plastic material and plastic.
2. The technology of the main shaft sealed apparatus has got the national patent. ( patent number ZL96Z430641) with electric and steam heating functions.
3. Two layer of sealing technology is adopted in the pot cover. The opening of the heating mixed cover adopted the air opening device and the opening of the cooling mixed cover adopted hydraulic pressure control system.
4. The electrical control section with the programmable logic control adopted well-known imported meters and control components.
5.It is equipped with the pulse dust-cleaning recovery device.
6. The blades have been passed the test of the dynamic and static balance testing machine
7.you may choose the simple and easy feeding system.
